Product Protection
Stable adhesive property
Suitable for different protection conditions
Available with protective film of PET,PP,PE and other materials
Supply customized solutions
Product Advantages
Category
|
产品分类 |
产品型号 |
|---|---|
|
Three-layer silicone screen protector film |
PETROIS PET9100H-25C |
|
Transparent Silicone protective film |
PETROIS PET950-3C |
|
Anti-static PU adhesive protective film |
PETROIS PET750D-2C |
|
Ultra high temperature resistance acrylic protective film |
PETROIS PET850-5C |
|
Anti-static silicone battery process protective film |
PETROIS PET9125D-23C |
|
Transparent CPP protective film |
PETROIS CPP845-20C |
Remark:The above films can be customized for clients according to their specific application demands.
Performance
|
Property test items |
||||
|---|---|---|---|---|
|
Thickness of protective layer |
60±2 | μm | GB/T7125-2014 | |
|
Peeling strength |
≤3 | g/25mm | GBT2792-2014(sampling from MD) | |
|
Scratch resistant coating thickness |
2±1 | μm | GB/T7125-2014 | |
|
Gloss graded PET thickness |
100±2 | μm | GB/T7125-2014 | |
|
Silicone layer thickness |
28±3 | μm | GB/T7125-2014 | |
|
Total thickness of used layers |
130±5 | μm | GB/T7125-2014 | |
|
Peeling strength |
3-6 | g/25mm | GBT2792-2014(sampling from MD) | |
|
Release layer thickness |
50±2 | μm | GB/T7125-2014 | |
|
Tearing strength |
≤15 | g/25mm | GB,T2792-2014(sampling from MD) | |
|
Transmittance of the used layer |
≥92 | % | ASTM D1003 | |
|
Moldy rate of the used layer |
≤1.2 | % | ||
|
High temperature and high humidity |
No retained adhesive and no bubble |
% | / | |
|
Anti-scratch coating and wear resistance |
1000 times without obvious scratches on the surface |
/ | / | |
|
Water drops angle of the anti-scratch coating |
≥105 | º | GB/T 30693-2014 | |
|
Anti-static value |
105-11 | Ω | / | |
|
Applicable temperature |
-5～120 | ℃ | / | |
*The information on Weifu products and their applications provided in this datasheet is based on testing of representative material and the results are believed to be reliable as at the date of publication advised below. The information does not constitute a warranty or guarantee, either expressly or implied, of any specific product attribute or the suitability of products for specific applications. For particular technical requirements or specifications, please contact Weifu.
Application
With stable adhesive property,protective films of polyurethane (PU) adhesive series, acrylic adhesive series, and silicone adhesive series are suitable for different protection conditions.We can provide protective films of PET, PP, PE, PI, PVC, TPU and other materials for different product protection. Base on specific application demands,We supply customized solutions and provide protective films with anti-static, scratch resistant, AG and AF functions.
